Technical data
|
Biber 3/21 |
| Chipping system |
disque wheel |
| Infeed opening |
21 x 24 cm |
| No. of knives |
3 Stück |
| Chip length adjustment |
1-3 cm |
| Secondary knife for exact fine wood chips |
● |
| Hydraulic tank |
35 Liter |
| Drive power via PTO |
ab 30 bis 80 kW |
| Rotational speed of PTO shaft |
540 – 1000 U/min |
| Grinding device |
● |
| Prolongation ejection tube |
○ |
| Dimensions l x b x h (m) * |
Three-point-attelage (serie) |
| Working position |
2,61 x 1,55 x 3,21 |
| Transport position |
2,61 x 1,55 x 2,43 |
| Weight three-point ca.* |
1.080 kg |
* depending on the fittings ● serie ○ optional extra available at extra cost
Feeding area according to the latest findings:
safe, ergonomic, functional
also excellent for bulky raw material
Well thought-out safety device
increased safety with rope on all 4 sides of feeding hopper: both pressing and pulling forwards the safe-stop signal to the control
Certified
by the German GS (Guaranteed Safety) quality mark
Control of the machine
easy, intuitive control by sensor key
enables a quick startup
SPS Control
mode selection depending on desired quality of wood chips:
fine, medium, coarse or user-defined
automatic error detection and emergency mode
clear display that shows daily- and total hours counter
Hydraulic system
high quality hydraulic components and a large amount of oil guarantee high performance and long life
Service-friendliness
all lubrication points accessible from the outside without opening a guard
Sharpener fitted
Anytime sharp knives thanks to the grinding device mounted on the machine
